TPIC6B273DWRG4

monolithic, high-voltage, medium-current, power logic octal D-type latch, 500mA, 7V, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.50~0.90 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.50~0.90

PartNumber:: TPIC6B273DWRG4

Brand:: Texas Instruments - TI | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Selina's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-08-09

From Other Seller

Part Number:TPIC6B273DWRG4
US $0.50 - 0.90
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The TPIC6B273DWRG4 is a monolithic, high-voltage, medium-current, power logic octal D-type latch with DMOS-transistor outputs designed for use in systems that require relatively high load power. The device contains a built-in voltage clamp on the outputs for inductive transient protection. Power driver applications include relays, solenoids, and other medium-current or high-voltage loads.

Parametrics

TPIC6B273DWRG4 Absolute maximum ratings: (1)Logic supply voltage, VCC: 7V; (2)Logic input voltage range, VI: –0.3V to 7V; (3)Power DMOS drain-to-source voltage, VDS: 50V; (4)Continuous source-to-drain diode anode current: 500mA; (5)Pulsed source-to-drain diode anode current: 1A; (6)Pulsed drain current, each output, all outputs on, ID, TC = 25℃: 500mA; (7)Continuous drain current, each output, all outputs on, ID, TC = 25℃: 150mA; (8)Peak drain current single output, IDM,TC = 25℃: 500mA; (9)Single-pulse avalanche energy, EAS: 30mJ; (10)Avalanche current, IAS: 500mA; (11)Operating virtual junction temperature range, TJ: –40℃ to 150℃; (12)Operating case temperature range, TC: –40℃ to 125℃; (13)Storage temperature range: –65℃ to 150℃; (14)Lead temperature 1,6mm (1/16 inch) from case for 10 seconds: 260℃.

Features

TPIC6B273DWRG4 Features: (1)Low rDS(on): 5 W Typical; (2)Avalanche Energy: 30mJ; (3)Eight Power DMOS-Transistor Outputs of 150mA Continuous Current; (4)500-mA Typical Current-Limiting Capability; (5)Output Clamp Voltage: 50V; (6)Low Power Consumption.
