Product Summary

The UC3770AN is a kind of high-performance full bridge driver that offers higher current and lower saturation voltage than the UC3717 and the UC3770. Included in the UC3770AN are LS-TTL compatible logic inputs, current sense, monostable, thermal shutdown, and a power H-bridge output stage. Two UC3770AN and a few external components form a complete microprocessor-controllable stepper motor power system.

Parametrics

UC3770AN absolute maximum ratings: (1)Logic Supply Voltage, VCC: 7V; (2)Output Supply Voltage, VMM: 50V; (3)Logic Input Voltage (Pins 7, 8, 9): 6V; (4)Analog Input Voltage (Pin 10): VCC; (5)Reference Input Voltage (Pin 11): 15V; (6)Logic Input Current (Pins 7, 8, 9): –10mA; (7)Analog Input Current (Pins 10, 11): –10mA; (8)Output Current (Pins 1, 15): ± 2A; (9)Junction Temperature, TJ: +150℃.

Features

UC3770AN features: (1)Full-Step, Half-Step and Micro-Step Capability; (2)Bipolar Output Current up to 2A; (3)Wide Range of Motor Supply Voltage: 10-50V; (4)Low Saturation Voltage; (5)Wide Range of Current Control: 5mA-2A; (6)Current Levels Selected in Steps or Varied Continuously; (7)Thermal Protection and Soft Intervention.

Diagrams

UC3770AN circuit diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
UC3770AN
UC3770AN

Texas Instruments

Motor / Motion / Ignition Controllers & Drivers HP Stepper

Data Sheet

0-1: $4.70
1-25: $3.85
25-100: $2.96
100-250: $2.78
UC3770ANG4
UC3770ANG4

Texas Instruments

Motor / Motion / Ignition Controllers & Drivers HP Stepper

Data Sheet

0-1: $4.69
1-25: $3.85
25-100: $2.96
100-250: $2.78
