TMS320C6211BZFN150

TMS320C6211BZFN150, Fixed-point, digital signal processors, BGA, 32-Bit, 150MHz, 1200MIPS

Rated 5 Rating 5 | reviews | Write a review

Price:: US $21.10~35.60 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $21.10~35.60

PartNumber:: TMS320C6211BZFN150

Brand:: Texas Instruments - TI | Pack: BGA | D/C: 05+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Selina's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-08-12

From Other Seller

Part Number:TMS320C6211BZFN150
US $21.10 - 35.60
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
HEF4051BT

US $0.15 - 1.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The TMS320C6211BZFN150 DSP composes one of the fixed-point DSP families in the TMS320C6000. DSP platform. The TMS320C6211BZFN150 is based on the high-performance, advanced VelociTI. very-long-instruction-word (VLIW) architecture developed by Texas Instruments (TI), making the TMS320C6211BZFN150 an excellent choice for multichannel and multifunction applications. The TMS320C6211BZFN150 has a complete set of development tools which includes: a new C compiler, an assembly optimizer to simplify programming and scheduling, and a Windows. debugger interface for visibility into source code execution.

Parametrics

TMS320C6211BZFN150 absolute maximum ratings: (1)Supply voltage range, CVDD: -0.3 V to 2.3 V; (2)Supply voltage range, DVDD: -0.3 V to 4 V; (3)Input voltage range: -0.3 V to 4 V; (4)Output voltage range: -0.3 V to 4 V; (5)Operating case temperature ranges, TC: 0℃ to 90℃; (6)Storage temperature range, Tstg: -65℃ to 150℃.

Features

TMS320C6211BZFN150 features: (1)Excellent Price/Performance Digital Signal Processors (DSPs); (2)VelociTI. Advanced Very Long Instruction Word (VLIW) C62x. DSP Core (C6211/11B); (3)Instruction Set Features; (4)L1/L2 Memory Architecture; (5)32-Bit External Memory Interface; (6)Enhanced Direct-Memory-Access (EDMA) Controller (16 Independent Channels); (7)16-Bit Host-Port Interface (HPI)- Access to Entire Memory Map; (8)Two 32-Bit General-Purpose Timers; (9)Flexible Phase-Locked-Loop (PLL) Clock Generator; (10)3.3-V I/Os, 1.8-V Internal.
