CD4053BCMX

single 8-Channel multiplexer, SOIC, 3V to 15V, 80Ω, CD4053BCMX

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.28~0.77 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.28~0.77

PartNumber:: CD4053BCMX

Brand:: Fairchild Semiconductor - Fairchild | Pack: SOIC | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Selina's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-08-10

From Other Seller

Part Number:CD4053BCMX
US $0.28 - 0.77
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
HCPL-7800A

US $2.50 - 4.10 / Piece
(0) Remove
Quantity:

piece

Product Summary

The CD4053BCMX is a single 8-Channel multiplexer having three separate digital control inputs, A, B, and C, and an inhibit input. Each control input selects one of a pair of channels which are connected in a single-pole, double-throw configuration. The applications of the CD4053BCMX include Analog and Digital Multiplexing and Demultiplexing, A/D and D/A Conversion, Signal Gating.

Parametrics

CD4053BCMX absolute maximum ratings: (1)DC Supply Voltage (VDD): -0.5 VDC to +18 VDC; (2)nput Voltage (VIN): -0.5 VDC to VDD+0.5 VDC; (3)Storage Temperature Range (TS): - 65℃ to 150℃ ; (4)Power Dissipation (PD): Dual-In-Line, 700 mW; Small Outline, 500 mW; (5)Lead Temp. (TL) (soldering, 10 sec.): 260℃.

Features

CD4053BCMX features: (1)Wide Range of Digital and Analog Signal Levels:Digital:3V to 15V, Analog to 15VP-P; (2)Low ON Resistance, 80Ω (Typ) Over 15VP-P Signal Input Range for VDD-VEE = 15V; (3)High OFF Resistance, Channel Leakage of ±10pA (Typ) at VDD-VEE = 10V; (4)Logic-Level Conversion for Digital Addressing Signals of 3V to 15V (VDD-VSS = 3V to 15V) to Switch Analog Signals to 15VP-P (VDD-VEE = 20V); (5)Matched Switch Characteristics, rON = 5Ω (Typ) for VDD-VEE = 15V; (6)Very Low Quiescent Power Dissipation Under All Digital-Control Input and Supply Conditions, 1μW (Typ) at VDD-VSS = VDD-VEE = 10V; (7)Binary Address Decoding on Chip.
