Product Summary
The BT169G is a Passivated, sensitive gate thyristor in a SOT54 plastic package, which is designed for general purpose switching and phase control applications.
Parametrics
BT169G absolute maximum ratings: (1)VDRM, VRRM, repetitive peak off-state voltages: 600 V; (2)IGM, peak gate current: 1 A; (3)VGM, peak gate voltage: 5 V; (4)VRGM, peak reverse gate voltage: 5 V; (5)PGM, peak gate power: 2 W; (6)PG(AV), average gate power, over any 20 ms period: 0.1 W; (7)Tstg, storage temperature: -40 to +150℃; (8)Tj, junction temperature: 125℃.
Features
BT169G features: (1)Designed to be interfaced directly to microcontrollers, logic integrated circuits and other low power gate trigger circuits; (2)Mounting Style: SMD/SMT; (3)Package / Case: SOT-54; (4)Packaging: Tube.
Diagrams
Image | Part No | Mfg | Description | ![]() |
Pricing (USD) |
Quantity | ||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
![]() |
![]() BT169G AMO |
![]() NXP Semiconductors |
![]() SCRs AMMORA SCR |
![]() Data Sheet |
![]() Negotiable |
|
||||||||||||
![]() |
![]() BT169G,112 |
![]() NXP Semiconductors |
![]() SCRs .8A 600V |
![]() Data Sheet |
![]()
|
|
||||||||||||
![]() |
![]() BT169G,126 |
![]() NXP Semiconductors |
![]() SCRs AMMORA SCR |
![]() Data Sheet |
![]()
|
|
||||||||||||
![]() |
![]() BT169G/DG,126 |
![]() NXP Semiconductors |
![]() Rectifiers SILICON CONTROLLED RECTIFIERS |
![]() Data Sheet |
![]()
|
|
||||||||||||
![]() |
![]() BT169G-L,412 |
![]() NXP Semiconductors |
![]() Rectifiers Silicon Controlled Rectifier |
![]() Data Sheet |
![]()
|
|
