Product Summary
The SN74AHC1G08DBVR is a single 2-input positive-AND gate. The device performs the Boolean function Y= A * B or Y= A+B in positive logic.
Parametrics
SN74AHC1G08DBVR absolute maximum ratings: (1)Supply voltage range, VCC:-0.5 V to 7 V; (2)Input voltage range, VI:-0.5 V to 7 V; (3)Output voltage range, VO:-0.5 V to VCC + 0.5 V; (4)Input clamp current, IIK (VI < 0):-20 mA; (5)Output clamp current, IOK (VO < 0 or VO > VCC):±20 mA; (6)Continuous output current, IO (VO = 0 to VCC):±25 mA; (7)Continuous current through VCC or GND:±50 mA; (8)Package thermal impedance, θJA:206℃/W ; (9)Storage temperature range, Tstg:-65℃ to 150℃.
Features
SN74AHC1G08DBVR features: (1)Operating Range of 2 V to 5.5 V; (2)Max tpd of 7 ns at 5 V; (3)Low Power Consumption, 10μA Max ICC; (4)±8mA Output Drive at 5 V; (5)Schmitt Trigger Action at All Inputs Makes the Circuit Tolerant for Slower Input Rise and Fall Time; (6)Latch-Up Performance Exceeds 250 mA Per JESD 17; (7)ESD Protection Exceeds JESD 22:2000-V Human-Body Model (A114-A),200-V Machine Model (A115-A),1000-V Charged-Device Model(C101).
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 SN74AHC1G08DBVR |
Texas Instruments |
Gates (AND / NAND / OR / NOR) Single 2-Input |
Data Sheet |
|
|
||||||||||||
|
SN74AHC1G08DBVRE4 |
Texas Instruments |
Gates (AND / NAND / OR / NOR) Single 2-Input |
Data Sheet |
|
|
||||||||||||
|
SN74AHC1G08DBVRG4 |
Texas Instruments |
Gates (AND / NAND / OR / NOR) Single 2-Input |
Data Sheet |
|
|
||||||||||||
