Product Summary
The LC75411ES is an electronic volume controller that enables control of volume, balance, fader, bass/treble, loudness, input switching, and input gain using only a small number of external components.
Parametrics
LC75411ES absolute maximum ratings: (1)Maximum supply voltage, VDD max: 11 V; (2)Maximum input voltage, VIN max, All input pins: VSS – 0.3 to VDD + 0.3 V; (3)Allowable power dissipation, Pd max, Ta≦85℃, when mounted on board: 600 mW; (4)Operating temperature, Topr: –40 to +85 ℃; (5)Storage temperature, Tstg: –50 to +125 ℃.
Features
LC75411ES features: (1)On-chip buffer amplifier cuts down number of external components; (2)Low switching noise generated by on-chip switch through use of silicon gate CMOS process, for low switching noise when there is no signal; (3)Low switching noise when there is a signal due to use of on-chip zero-cross switching circuit; (4)On-chip 1/2 VDD reference voltage circuit; (5)Controls performed with serial input (CCB).
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 LC75411ES |
Other |
|
Data Sheet |
Negotiable |
|
||||
